Flange Panel Mount Gauge 4 Inch
Front flange panel mount gauge 4"
dyluniad fflans dur di-staen, mesurydd achos dur di-staen, maint a deial wedi'i addasu. gwasanaeth OEM. mesurydd cysylltiad canol mount pres. olew llenwi fflans mount math mesurydd math. cysylltwch â YCpressuregauge am fwy o fanylion.
Disgrifiad
Front Flange Panel Mount Gauge 4 inch (4'')
Industrial Grade pressure gauges feature heavy{{0}}duty sensing elements and a stainless steel case for protection in harsh environments. Industrial gauges offer greater accuracy than commercial gauges and are typically used in more demanding applications. The pressure connection and wetted parts are made of copper alloy (brass). Recommended panel hole cutout dimension is 4.0" diameter, flange has 3 mounting holes (0.19" dia.) equally spaced on a 4.57" bolt circle.
Specifications of this flange panel mount gauge 4'':
| Amrediad pwysau | 0- 160 psi, neu wedi'i addasu |
| Maint | 4'' , 100mm |
| Cysylltiad | 1/4'' NPT flange panel mount |
| Cywirdeb | ynghyd â /- 1 y cant o'r rhychwant |
| Rhannau wedi'u gwlychu | Aloi copr |
| Achos | 304 o ddur di-staen |
| Ffenestr | Acrylig, Buna-N gasged |
